PEI Guide

Introduction

Polyetherimide, commonly known as PEI, is a high-performance amorphous thermoplastic used for components that require high heat resistance, mechanical strength, dimensional stability, flame resistance, and reliable electrical performance.

PEI is frequently selected for demanding applications in aerospace, automotive, electrical and electronics, medical equipment, industrial systems, and laboratory equipment. It can also provide transparent amber-colored molded parts, making it unusual among high-temperature engineering plastics.

However, PEI requires higher processing temperatures and stricter moisture control than many conventional plastics. Successful PEI injection molding depends on proper material drying, machine capability, mold temperature control, gate design, stress management, and part geometry.

This guide covers the main properties, applications, design requirements, and injection molding considerations engineers should evaluate when selecting PEI.

What Is PEI?

PEI stands for polyetherimide, an amorphous high-performance thermoplastic characterized by its rigid molecular structure and high glass transition temperature.

Unlike semi-crystalline materials, PEI does not form a highly ordered crystalline structure during cooling. Its amorphous structure helps provide:

• Predictable molding shrinkage
• Good dimensional stability
• Consistent mechanical properties
• Transparent material options
• Good surface appearance
• Stable electrical insulation

PEI combines high-temperature capability with relatively good processability compared with some higher-cost specialty polymers.

Commercial PEI materials are available in unfilled, glass-fiber-reinforced, high-flow, wear-resistant, electrically modified, and application-specific grades.

Key Properties of PEI

High Heat Resistance

One of the principal advantages of PEI is its ability to retain mechanical properties at elevated temperatures.

PEI may be considered for components exposed to:

• Continuous high operating temperatures
• Repeated thermal cycling
• Heated electrical systems
• Automotive under-hood environments
• Sterilization processes
• Aerospace interior conditions
• Industrial equipment near heat sources

Some commercial PEI families have a glass transition temperature around 217°C and grade-dependent relative thermal indices reaching approximately 180°C. Actual service capability depends on grade, mechanical loading, part geometry, exposure duration, and regulatory requirements.

High Strength and Stiffness

PEI provides a strong combination of tensile strength, flexural strength, stiffness, and creep resistance.

These characteristics make it useful for:

• Structural housings
• Load-bearing brackets
• Electrical components
• Precision instrument parts
• Metal-replacement applications
• Components exposed to sustained loads

Glass-fiber-reinforced grades can provide greater rigidity and dimensional control than unfilled PEI.

However, increased reinforcement may also affect surface appearance, impact performance, fiber orientation, tool wear, and weld-line strength.

Dimensional Stability

PEI generally offers predictable shrinkage and good dimensional stability because of its amorphous structure.

It is suitable for molded parts containing:

• Tight assembly interfaces
• Precision holes
• Alignment features
• Electrical terminal locations
• Flat mounting surfaces
• Metal inserts
• Closely controlled tolerances

Dimensional performance still depends on wall thickness, gate position, fiber orientation, cooling uniformity, residual stress, and molding conditions.

Glass-reinforced PEI may provide a coefficient of thermal expansion closer to certain metals, which can be useful for overmolded sensors and electrical assemblies.

Inherent Flame Resistance

Many PEI grades provide inherent flame resistance without relying on heavily halogenated flame-retardant systems.

Depending on the specific grade and wall thickness, PEI materials may support demanding flame, smoke, and toxicity requirements.

This makes PEI particularly valuable for:

• Aircraft interiors
• Rail transportation
• Electrical equipment
• Electronic housings
• Battery and power components
• Public transportation systems

Flammability classifications are grade-specific. Engineers must verify the applicable UL, aerospace, railway, or industry certification for the exact material and molded thickness.

Low Smoke Emission

PEI is commonly considered for transportation applications where fire behavior involves more than flame resistance alone.

Selected grades can provide:

• Low smoke generation
• Low toxic-gas emission
• Inherent flame resistance
• Stable mechanical properties at elevated temperatures

These characteristics are especially relevant for aircraft, railway, and enclosed transportation environments.

Good Electrical Properties

PEI provides stable insulating and dielectric properties across a broad temperature range.

Common electrical applications include:

• Connector housings
• Coil bobbins
• Switch components
• Circuit protection parts
• Sensor housings
• High-temperature insulators
• Semiconductor equipment components

Electrical performance can be influenced by moisture, temperature, frequency, wall thickness, reinforcement, and material formulation.

The selected grade should be evaluated using the electrical requirements of the actual application.

Transparent Material Options

Unfilled PEI is naturally transparent with an amber appearance.

This makes PEI suitable for components requiring both high heat resistance and visual inspection, such as:

• Fluid-handling components
• Instrument covers
• Sight windows
• Laboratory equipment
• Medical equipment housings
• Lighting and optical-support components

PEI is not water-clear like some polycarbonate or acrylic grades. Its natural amber color should be considered during product design.

Opaque and custom-colored grades are also available.

Chemical and Hydrolytic Resistance

PEI provides resistance to a broad range of oils, fuels, alcohols, cleaning agents, and selected industrial chemicals.

It may also offer useful hydrolytic stability for components exposed to hot water, steam, or repeated cleaning cycles.

However, PEI is not universally resistant to all chemicals. Certain strong bases, chlorinated solvents, or aggressive chemicals may cause stress cracking, swelling, discoloration, or property loss.

Chemical compatibility depends on:

• Chemical concentration
• Exposure temperature
• Exposure time
• Molded-in stress
• Applied mechanical stress
• Material grade

Testing under realistic service conditions is recommended.

Common Types of PEI Grades

Unfilled PEI

Unfilled PEI provides the material’s typical combination of:

• High heat resistance
• Natural amber transparency
• Good mechanical strength
• Electrical insulation
• Dimensional stability
• Surface quality

It is commonly used when transparency, appearance, or a balanced property profile is required.

Glass-Fiber-Reinforced PEI

Glass-fiber-reinforced grades provide increased:

• Stiffness
• Strength
• Dimensional stability
• Creep resistance
• Heat performance
• Control of thermal expansion

Common reinforcement levels may range from approximately 10% to 40%, although available formulations vary by material supplier.

These grades are often selected for structural, automotive, electrical, and industrial components.

High-Flow PEI

High-flow grades are designed to improve mold filling in:

• Thin-wall components
• Long flow paths
• Complex cavities
• Fine ribs
• Multi-cavity molds
• Precision electrical parts

Higher flow can improve processability, but grade selection must still account for mechanical, thermal, chemical, and regulatory requirements.

Specialty PEI Grades

Specialty PEI formulations may be developed for:

• Medical and healthcare equipment
• Food-contact applications
• Aerospace interiors
• Wear and friction resistance
• Enhanced chemical resistance
• Improved impact performance
• Metallization
• Infrared transparency
• Electrical conductivity
• Static dissipation

Regulatory compliance should always be verified for the specific grade rather than assumed from the general PEI material family.

Common Applications of PEI

Aerospace Components

PEI is widely associated with aerospace applications because it offers high heat resistance, low smoke emission, inherent flame resistance, and good strength-to-weight performance.

Potential applications include:

• Aircraft interior panels
• Seating components
• Lighting housings
• Air-management components
• Passenger service components
• Electrical brackets
• Interior structural parts
• Window-related components

Aerospace projects must verify grade-specific fire, smoke, toxicity, traceability, and documentation requirements.

Electrical and Electronic Components

PEI is used in electrical systems requiring dimensional stability and reliable insulation at elevated temperatures.

Applications include:

• Connector housings
• Switch components
• Coil bobbins
• Circuit-breaker parts
• Electrical insulators
• Sensor housings
• Semiconductor-processing components
• High-temperature electronic enclosures

Its thermal stability can help components maintain alignment and insulation performance in demanding environments.

Automotive and EV Components

Automotive applications increasingly require materials capable of handling heat, electrical loads, chemicals, and tight packaging spaces.

PEI may be considered for:

• Under-hood sensors
• Electrical connectors
• EV charging components
• Lighting reflectors
• Battery-system components
• Motor and coil components
• Electronic control housings
• Fluid-system components

Selected PEI grades can provide dimensional stability under combined heat and moisture exposure, which is important for sensor and connector applications.

Medical and Healthcare Equipment

PEI may be used for reusable medical equipment and diagnostic components requiring heat resistance, dimensional stability, and repeated cleaning or sterilization.

Potential applications include:

• Sterilization trays
• Instrument handles
• Diagnostic equipment housings
• Fluid-management parts
• Medical device components
• Laboratory instrument parts
• Reusable healthcare components

Medical applications require careful review of:

• Biocompatibility
• Sterilization compatibility
• Chemical resistance
• Regulatory status
• Color stability
• Traceability
• Manufacturing controls

A standard industrial PEI grade should not automatically be treated as a medical-grade material.

Industrial Equipment

PEI is used in industrial environments where conventional plastics may lose stiffness, deform, or degrade under heat.

Examples include:

• High-temperature housings
• Pump components
• Valve components
• Electrical insulation
• Instrumentation parts
• Precision fixtures
• Process-equipment components
• Semiconductor equipment parts

Laboratory and Food Equipment

Selected PEI grades may be used for transparent or reusable components exposed to heat, steam, cleaning agents, or food-contact environments.

Potential applications include:

• Laboratory trays
• Instrument covers
• Fluid containers
• Food-service trays
• Coffee-machine components
• Heating containers
• Kitchen equipment components

Only grades with the appropriate food-contact or regulatory documentation should be used for these applications.

PEI Part Design Considerations

Maintain Consistent Wall Thickness

Uniform wall thickness supports consistent filling, packing, cooling, and shrinkage.

Designers should:

• Avoid isolated thick sections
• Use gradual thickness transitions
• Core out heavy areas
• Maintain balanced flow paths
• Add ribs instead of increasing wall thickness
• Use smooth transitions between features

Large thickness changes may produce sink marks, voids, residual stress, or uneven cooling.

Use Appropriate Corner Radii

Sharp internal corners create stress concentrations and can restrict material flow.

Rounded corners help:

• Reduce cracking risk
• Improve filling
• Lower molded-in stress
• Increase structural strength
• Improve fiber flow in reinforced grades

Adequate radii are especially important for parts exposed to mechanical loads, thermal cycling, chemicals, or repeated assembly.

Design Ribs Carefully

Ribs can improve stiffness while reducing material use and cooling time.

PEI rib design should consider:

• Rib thickness
• Root radius
• Draft angle
• Spacing
• Gate location
• Flow direction
• Ejection support

Overly thick ribs may cause sink marks, internal stress, and long cooling times.

Apply Adequate Draft

PEI components require sufficient draft for reliable ejection.

Draft requirements depend on:

• Part depth
• Surface texture
• Material grade
• Reinforcement level
• Mold finish
• Ejection system
• Cosmetic requirements

Glass-filled grades and textured surfaces generally require more draft than smooth, unfilled parts.

Manage Stress in Snap-Fits

PEI is stiff and strong, but it is generally less forgiving than highly flexible commodity plastics.

Snap-fit features should include:

• Controlled deflection
• Generous root radii
• Smooth strain distribution
• Realistic assembly tolerances
• Adequate lead-in geometry
• Protection from chemical exposure under stress

Prototype testing is recommended for repeated snap-fit assembly.

Design Bosses for Assembly Loads

Bosses used for screws, inserts, or mounting features should avoid excessive local stress.

Potential risks include:

• Cracking during screw installation
• Hoop stress
• Weld-line weakness
• Sink marks
• Excessive material thickness
• Long-term creep

Thread-forming screws, press-fit inserts, ultrasonic inserts, and heat-staked features should be validated with production-intent parts.

Consider Metal Inserts

PEI is often used in insert-molded components because of its heat resistance and dimensional stability.

Design considerations include:

• Insert positioning
• Mechanical retention
• Thermal expansion differences
• Plastic thickness around the insert
• Weld-line location
• Preheating requirements
• Molded-in stress

Sharp edges on metal inserts should be avoided because they can concentrate stress in the surrounding plastic.

PEI Injection Mold Design Considerations

Gate Location

Gate location affects:

• Material flow
• Weld-line position
• Fiber orientation
• Pressure requirements
• Surface appearance
• Residual stress
• Dimensional stability

The gate should allow the cavity to fill without excessive pressure or shear.

Weld lines should be kept away from:

• Load-bearing features
• Screw bosses
• Snap-fit roots
• Sealing surfaces
• Cosmetic areas
• Precision electrical features

Runner Design

Runner systems should minimize excessive pressure loss and material residence time.

Recommended design principles include:

• Balanced cavity filling
• Smooth transitions
• Short flow paths
• Adequate runner size
• Minimal dead zones
• Controlled shear
• Appropriate gate freeze-off

Hot-runner systems must be designed specifically for high-temperature engineering materials.

Mold Venting

Inadequate venting may cause:

• Burn marks
• Short shots
• Poor weld lines
• Surface defects
• Gas trapping
• Material degradation

Vents should be located at:

• Ends of fill
• Deep ribs
• Bosses
• Weld-line areas
• Thin terminal features
• Insert locations

Vent dimensions must release air without allowing unacceptable flash.

Mold Temperature Control

PEI generally requires a higher mold temperature than many standard engineering plastics.

Uniform mold temperature helps improve:

• Flow
• Surface appearance
• Weld-line strength
• Dimensional consistency
• Stress control
• Cycle repeatability

Cooling channels should be designed to reduce hot spots and uneven cooling, especially around thick sections and metal inserts.

Tool Steel and Mold Construction

High processing temperatures and reinforced PEI grades can place significant demands on mold materials.

High-volume tooling may require:

• Hardened tool steels
• Wear-resistant gates
• Replaceable inserts
• Stable cavity support
• High-temperature seals and components
• Suitable mold surface treatments

Mold construction should account for operating temperature, production volume, reinforcement level, and tolerance requirements.

PEI Injection Molding Process Considerations

Material Drying

PEI is hygroscopic and must be dried properly before injection molding.

Insufficient drying may lead to:

• Surface streaks
• Splay
• Bubbles
• Reduced mechanical properties
• Material degradation
• Poor appearance
• Unstable processing

Drying temperature and time should follow the specific resin supplier’s recommendations.

Material should remain protected from ambient moisture after drying.

Melt Temperature

PEI requires relatively high melt temperatures.

A melt temperature that is too low may cause:

• Short shots
• High injection pressure
• Poor weld lines
• Incomplete details
• Poor surface replication

Excessive melt temperature or residence time may cause:

• Discoloration
• Gas generation
• Material degradation
• Black specks
• Reduced properties

Actual melt temperature should be verified rather than relying only on machine barrel settings.

Injection Speed

Moderate to fast injection may help maintain a stable flow front and fill complex features.

However, excessive injection speed can produce:

• Burn marks
• Jetting
• Flash
• Air trapping
• Excessive shear
• Residual stress

A staged injection-speed profile may be needed for complex parts.

Injection and Holding Pressure

PEI’s melt viscosity can require substantial pressure, especially in long or thin flow paths.

Pressure should be sufficient to fill the cavity without causing:

• Flash
• Mold separation
• Overpacking
• High residual stress
• Gate damage
• Difficult ejection

Holding pressure should compensate for shrinkage without unnecessarily stressing the molded part.

Residence Time

PEI should not remain at high processing temperature longer than necessary.

Excessive residence time may cause:

• Discoloration
• Degradation
• Gas formation
• Black specks
• Reduced mechanical performance

Machine barrel size should be appropriate for the shot weight and expected cycle time.

Stress Management

Because PEI is an amorphous material, excessive molding or assembly stress can increase sensitivity to chemical attack and environmental stress cracking.

Stress can be reduced through:

• Proper melt temperature
• Adequate mold temperature
• Balanced filling
• Controlled packing pressure
• Uniform wall thickness
• Rounded corners
• Correct ejection
• Appropriate assembly design

Common PEI Injection Molding Defects

Short Shots

Possible causes include:

• Inadequate drying
• Low melt temperature
• Low mold temperature
• Restricted gates
• Insufficient injection pressure
• Poor venting
• Excessive flow length

Corrective action may require changes to the process, gate, runner, venting, or part design.

Splay and Surface Streaks

Splay is commonly associated with moisture, trapped gas, contamination, or material degradation.

Potential solutions include:

• Improving material drying
• Protecting dried resin from moisture
• Reducing residence time
• Checking contamination
• Optimizing melt temperature
• Improving venting

Burn Marks

Burn marks may result from compressed air, excessive injection speed, high melt temperature, or material degradation.

Corrective actions may include:

• Improving venting
• Reducing end-of-fill speed
• Eliminating dead zones
• Reducing excessive residence time
• Reviewing gate location

Sink Marks and Voids

Sink marks and voids are often associated with thick sections or inadequate packing.

Possible solutions include:

• Reducing wall thickness
• Coring out heavy sections
• Optimizing ribs and bosses
• Adjusting holding pressure
• Increasing gate size
• Improving cooling balance

Warpage

Warpage may be caused by:

• Uneven wall thickness
• Unbalanced filling
• Uneven mold temperature
• Differential cooling
• Fiber orientation
• Excessive packing
• Poor gate location

Glass-filled grades require particular attention to flow direction and orientation-related shrinkage.

Cracking or Stress Cracking

Cracking may appear during molding, ejection, assembly, or chemical exposure.

Possible causes include:

• Sharp corners
• Excessive assembly interference
• High molded-in stress
• Poor chemical compatibility
• Insufficient draft
• Uneven ejection
• Weak weld lines

Part geometry, process conditions, assembly methods, and environmental exposure should be reviewed together.

PEI Compared with Other Engineering Plastics

Material selection depends on operating temperature, impact requirements, chemical exposure, dimensional tolerances, transparency, certifications, and project budget.

Material	Key Advantages	Main Limitations	Typical Applications
PEI	High heat resistance, inherent flame resistance, dimensional stability, strength, and transparent options	High processing temperature, moisture-sensitive processing, and higher cost	Aerospace interiors, sensors, electrical components, medical and industrial equipment
Polycarbonate	High impact strength, transparency, and easier processing	Lower long-term heat capability and reduced chemical resistance	Covers, housings, lenses, consumer electronics
PPS	Excellent chemical resistance, heat resistance, and dimensional stability	Usually opaque and more brittle in some applications	Pumps, sensors, automotive and industrial components
PEEK	Exceptional thermal, chemical, wear, and mechanical performance	Very high material and processing cost	Aerospace, medical implants, semiconductor and extreme industrial applications
PPSU	Excellent toughness, hydrolytic stability, and sterilization resistance	Higher cost and lower stiffness than reinforced PEI	Reusable medical devices, plumbing and fluid-handling components

PEI is generally preferred when a component needs a balance of high-temperature performance, stiffness, flame resistance, dimensional stability, and optional transparency.

PPS may be better for aggressive chemical environments, PPSU for repeated steam sterilization and impact resistance, and PEEK for applications requiring the highest overall performance.

How to Select the Right PEI Grade

Before choosing a PEI grade, engineers should evaluate:

1. Continuous and peak operating temperatures
2. Mechanical loads and creep requirements
3. Flame, smoke, and toxicity requirements
4. Electrical insulation requirements
5. Dimensional tolerances
6. Transparency or color requirements
7. Chemical exposure
8. Moisture and hot-water exposure
9. Sterilization method
10. Impact requirements
11. Required reinforcement level
12. Surface-finish expectations
13. Insert-molding requirements
14. Production volume
15. Industry certifications and regulatory requirements

Material selection should be supported by grade-specific technical data, DFM analysis, prototype testing, and production molding trials.

Conclusion

PEI is a high-performance thermoplastic that provides an effective balance of heat resistance, mechanical strength, dimensional stability, flame resistance, and electrical insulation.

Its main advantages include:

• Long-term high-temperature performance
• High strength and stiffness
• Good dimensional stability
• Inherent flame resistance
• Low smoke characteristics
• Reliable electrical properties
• Transparent grade options
• Good hydrolytic and chemical resistance

However, PEI requires proper drying, high-temperature processing equipment, controlled mold temperatures, careful stress management, and precision mold design.

Early collaboration between product designers, material suppliers, and injection molding engineers helps reduce tooling risks and improve production consistency.

Need Engineering Support?

Developing a high-temperature, flame-resistant, transparent, or precision PEI component?

AccuMolds provides engineering and manufacturing support for custom injection molding projects, including:

• Material and grade selection
• Design for manufacturability analysis
• Mold-flow and gate-location review
• Precision mold design and manufacturing
• Prototype and production tooling
• Insert molding
• High-temperature injection molding
• Dimensional inspection and quality planning

Send us your 2D or 3D drawings, material requirements, estimated production volume, tolerances, certifications, and target schedule. Our engineering team will review your project and recommend a practical manufacturing solution.

👉 Request a Quote
