Material Selection Guide

Introduction

Choosing a plastic for an injection molded component is not simply a matter of finding the material with the highest strength, heat resistance, or lowest price.

The correct material must perform as part of an entire system.

Mechanical loading, operating temperature, chemical exposure, dimensional requirements, appearance, regulatory requirements, part geometry, molding behavior, production volume, and cost all influence the final decision.

A material that performs extremely well in one area may introduce unnecessary cost or manufacturing complexity in another.

For this reason, effective material selection should begin with product requirements rather than a preferred resin name.

This guide provides a practical framework for selecting thermoplastics for injection molded products and identifying when additional material testing, DFM review, or manufacturing validation may be required.

Start With the Application Requirements

Before comparing ABS, PC, Nylon, POM, PEEK, PP, or any other polymer, define what the finished component must actually do.

Start by documenting:

• Mechanical loads
• Impact requirements
• Operating temperature
• Chemical exposure
• Moisture and humidity
• UV or outdoor exposure
• Dimensional tolerances
• Surface appearance
• Electrical requirements
• Regulatory requirements
• Expected service life
• Production volume
• Target manufacturing cost

This step prevents overengineering.

For example, selecting a very high-performance polymer may offer impressive datasheet values but provide little practical benefit if the component operates at room temperature under low mechanical load.

Material selection should therefore focus on the requirements that determine product success.

1. Mechanical Performance

Mechanical requirements are often the first screening factor.

Engineers should consider more than tensile strength.

Important characteristics may include:

• Stiffness
• Toughness
• Impact resistance
• Fatigue resistance
• Creep resistance
• Flexibility
• Wear resistance
• Friction

Different applications prioritize different properties.

A structural housing may require rigidity and impact resistance.

A snap-fit feature may require controlled flexibility and repeated deflection.

A gear or sliding mechanism may prioritize wear and friction.

A living hinge may depend heavily on fatigue behavior.

This is why there is rarely a single material that is "strongest" for every application.

The material should be selected according to the actual loading mode and expected service conditions.

2. Operating Temperature

Temperature can significantly change polymer behavior.

A material that is sufficiently stiff at room temperature may soften or creep when exposed to elevated temperatures.

When reviewing thermal requirements, consider:

• Continuous service temperature
• Short-term temperature peaks
• Thermal cycling
• Mechanical load at temperature
• Nearby heat sources
• Sterilization or cleaning temperatures
• Low-temperature impact requirements

General-purpose materials such as ABS, PP, and HDPE may be suitable for many normal environments.

Engineering plastics such as PC, Nylon, POM, PPS, PEI, and PEEK may be considered as thermal and mechanical requirements increase.

However, moving to a higher-temperature polymer can also increase resin cost and processing complexity.

The goal is to select enough thermal capability without specifying performance that the application does not require.

3. Chemical Resistance

Chemical exposure should be evaluated early because even a mechanically strong material may fail when exposed to an incompatible fluid.

Potential exposures include:

• Oils
• Fuels
• Acids
• Bases
• Alcohols
• Cleaning agents
• Disinfectants
• Solvents
• Lubricants
• Industrial fluids

Compatibility depends on more than chemical type.

Engineers should also consider concentration, exposure time, temperature, mechanical stress, and whether the contact is continuous or intermittent.

For demanding environments, materials such as PP, HDPE, PPS, PEEK, or certain specialty grades may be evaluated depending on the specific chemical system.

Chemical compatibility should ultimately be verified using data for the actual resin grade and representative application testing when failure would be critical.

4. Moisture Absorption and Environmental Stability

Moisture behavior can strongly affect dimensional and mechanical performance.

Some materials absorb very little moisture.

Examples include:

• POM
• PP
• HDPE

Others, particularly Nylon materials, can absorb moisture from the environment.

This may influence:

• Dimensions
• Stiffness
• Strength
• Assembly fit
• Long-term performance

The effect is not automatically a disadvantage.

Nylon remains an excellent engineering material for many structural and wear applications.

However, humidity must be considered when tight tolerances or environmental stability are important.

The material should therefore be evaluated in the condition in which the product will actually operate rather than only in the dry-as-molded state.

5. Dimensional Stability and Tolerances

Material selection and tolerance design cannot be separated.

Every polymer responds differently to:

• Mold shrinkage
• Cooling
• Fiber orientation
• Temperature
• Humidity
• Residual stress

Materials such as POM, LCP, PEI, and certain reinforced engineering polymers may be considered when dimensional stability becomes a major requirement.

However, material alone cannot guarantee precision.

Part geometry, wall thickness, gate location, cooling design, mold construction, processing consistency, and datum strategy also influence final dimensions.

Tight-tolerance applications should therefore be reviewed through DFM and tooling analysis rather than solved simply by choosing a "dimensionally stable" resin.

6. Wear and Friction

Moving mechanical components introduce another set of requirements.

Examples include:

• Gears
• Bearings
• Bushings
• Rollers
• Guides
• Sliding mechanisms
• Actuator components

POM is commonly considered for precision movement because of its favorable friction and dimensional characteristics.

Nylon also provides excellent wear performance and can be useful where toughness and fatigue resistance are important.

For more demanding wear environments, specialized PEEK or filled engineering grades may be evaluated.

But friction behavior depends on the entire mechanical system.

Engineers should consider:

• Mating material
• Surface finish
• Contact pressure
• Speed
• Lubrication
• Temperature
• Duty cycle

Wear performance should therefore be validated under realistic operating conditions for critical applications.

7. Impact Resistance

A rigid material is not necessarily an impact-resistant material.

This distinction is especially important for:

• Protective covers
• Equipment housings
• Handheld devices
• Safety-related components
• Automotive parts
• Industrial enclosures

Polycarbonate is frequently considered when high impact strength is required.

ABS may provide a useful balance of impact resistance, appearance, moldability, and cost for general-purpose housings.

HDPE may be attractive when toughness and flexibility are more important than high stiffness.

Geometry also plays a major role.

Sharp corners, abrupt wall transitions, weld lines, thin sections, and molded-in stress can reduce impact performance regardless of the polymer selected.

8. Optical and Cosmetic Requirements

Transparent and appearance-critical parts require additional material screening.

If transparency is required, potential candidates may include:

• Polycarbonate
• Acrylic / PMMA
• Transparent PEI grades
• Other specialty transparent polymers

Acrylic is often selected when optical clarity, weatherability, and surface appearance are priorities.

Polycarbonate is typically preferred when transparency must be combined with greater impact strength and higher heat capability.

For opaque cosmetic housings, ABS is widely considered because of its surface quality and coloring options.

Cosmetic requirements also affect tooling.

Mold polish, texture, gate position, weld lines, ejector locations, flow marks, and surface defects may become critical on visible components.

9. Electrical and Flame Requirements

Electrical and electronic products may require materials with specific dielectric, insulation, flame, or heat characteristics.

Applications include:

• Connectors
• Switch housings
• Insulators
• Electrical enclosures
• Coil components
• Sensor housings

Materials such as PC, Nylon, PPS, LCP, PEI, and PEEK may all be considered depending on the operating conditions.

Specific flame-retardant and certified grades are often required.

Do not assume that every grade within a polymer family carries the same electrical or flammability rating.

The exact commercial resin grade should be reviewed when compliance is part of the product specification.

10. Regulatory and Application Requirements

Certain industries introduce requirements beyond basic material performance.

Examples include:

Medical

Possible considerations:

• Biocompatibility
• Sterilization
• Chemical resistance
• Traceability
• Clean manufacturing

Food Contact

The selected resin grade may need appropriate food-contact compliance.

Automotive

Requirements may include:

• Heat
• Chemicals
• UV
• Vibration
• Flame resistance
• Long-term durability

Aerospace and Electronics

Designs may require:

• Flame performance
• Low weight
• Tight dimensional control
• Elevated-temperature performance
• Electrical insulation

Material selection should therefore include the required certification or compliance status at the specific grade level.

11. Injection Molding Processability

A material can meet every functional requirement and still create manufacturing problems if processing requirements are ignored.

Different polymers may require very different:

• Drying conditions
• Melt temperatures
• Mold temperatures
• Injection pressures
• Gate designs
• Cooling strategies
• Venting
• Residence-time control

Higher-performance materials generally require more capable processing equipment and tighter thermal control.

For example, high-temperature polymers such as PPS, PEI, and PEEK require more demanding molding conditions than common materials such as PP or ABS. AccuMolds' existing PPS, PEI, and other material guides likewise emphasize the relationship between resin behavior, drying, mold temperature, gate design, part geometry, and process stability.

Material selection should therefore include a manufacturing feasibility review before production tooling is finalized.

12. Match Material to Part Geometry

The same resin may behave very differently in two different component designs.

Review:

• Wall thickness
• Flow length
• Thin sections
• Ribs
• Bosses
• Snap fits
• Living hinges
• Undercuts
• Gate locations
• Weld-line locations

Thin-wall parts may require materials with favorable flow characteristics.

Precision connectors may prioritize dimensional stability and fine-feature filling.

Large flat covers may require careful consideration of shrinkage and warpage.

Highly structural components may benefit from reinforced grades.

The material and geometry should be developed together rather than treated as independent decisions.

13. Consider Reinforced and Modified Grades

Selecting the polymer family is only the first step.

Many materials are available as:

• Glass-filled grades
• Carbon-fiber-reinforced grades
• Impact-modified grades
• UV-stabilized grades
• Flame-retardant grades
• Lubricated grades
• Medical grades

Reinforcement can increase stiffness, strength, creep resistance, or dimensional performance.

However, fillers may also affect:

• Flow
• Shrinkage
• Warpage
• Surface finish
• Weld-line strength
• Tool wear

This is why a specification such as "Nylon" or "PC" is often not sufficient for production.

The final material should be defined at the grade level.

14. Evaluate Total Manufacturing Cost

Material price should never be the only cost criterion.

Total cost may also include:

• Drying
• Cycle time
• Mold temperature
• Tool wear
• Scrap
• Inspection
• Secondary operations
• Assembly
• Coatings
• Product failures

A more expensive polymer may reduce assembly problems or improve service life.

Conversely, specifying an ultra-high-performance material for a moderate application may unnecessarily increase resin and processing cost.

Good material selection aims for the lowest total manufacturing cost that reliably meets the product requirements.

A Practical Material Selection Process

A useful engineering workflow is:

1. Define the operating environment

Identify mechanical, thermal, chemical, dimensional, regulatory, and cosmetic requirements.

2. Identify the critical requirements

Separate essential requirements from desirable features.

3. Eliminate unsuitable material families

Remove materials that cannot meet temperature, chemical, impact, optical, or compliance requirements.

4. Compare candidate materials

Evaluate performance together with processing requirements and cost.

5. Select specific grades

Consider reinforcement, additives, certifications, and supplier data.

6. Review the part through DFM

Evaluate wall thickness, flow, shrinkage, gating, tolerances, and tooling feasibility.

7. Prototype and validate

Test the actual component under representative operating conditions when necessary.

Material suppliers and engineering-material companies similarly emphasize that selection should be linked with design recommendations, molding parameters, testing, and application-specific validation rather than datasheet comparison alone.
