Chemical Resistant Materials

Introduction

Chemical resistance is a critical material-selection factor for injection molded components used in laboratories, fluid-handling systems, industrial equipment, automotive systems, medical devices, chemical processing equipment, and many other demanding environments.

However, there is no single plastic that is resistant to every chemical.

A polymer that performs well in water, oils, or dilute acids may behave differently when exposed to concentrated solvents, elevated temperatures, cleaning chemicals, or continuous mechanical stress.

Selecting a chemical-resistant plastic therefore requires more than checking whether a material is listed as "compatible."

Engineers must consider the chemical, concentration, temperature, exposure time, mechanical loading, part geometry, and specific resin grade together.

This guide explains the major factors affecting chemical resistance and reviews commonly used injection molding materials for chemically demanding applications.

What Does Chemical Resistance Mean?

Chemical resistance describes a material's ability to maintain useful physical, mechanical, dimensional, and surface properties after exposure to a chemical environment.

Chemical exposure may cause effects such as:

• Swelling
• Softening
• Discoloration
• Surface crazing
• Cracking
• Loss of strength
• Dimensional change
• Environmental stress cracking
• Long-term degradation

Importantly, visible surface damage is not the only possible failure mode.

A molded component may appear normal while experiencing changes in mechanical performance or dimensions.

For this reason, chemical compatibility should be evaluated according to the actual service conditions rather than appearance alone.

1. Identify the Chemical Environment

The first step is to identify every chemical the component may contact during its service life.

Potential exposures may include:

• Acids
• Bases
• Alcohols
• Hydrocarbons
• Fuels
• Oils
• Lubricants
• Solvents
• Cleaning agents
• Disinfectants
• Detergents
• Automotive fluids
• Process chemicals

Do not evaluate only the primary process fluid.

A component may also be exposed to cleaning solutions, maintenance chemicals, assembly lubricants, or accidental spills.

For fluid-handling components, seals, valves, pumps, laboratory equipment, and industrial housings, these secondary exposures can influence material selection just as much as the main operating fluid.

2. Consider Concentration

Chemical concentration can significantly change compatibility.

A polymer that performs well in a dilute solution may not provide the same resistance to a concentrated chemical.

When reviewing material compatibility, define:

• Chemical identity
• Concentration
• Mixture composition
• Expected impurities
• Whether concentration changes over time

This becomes particularly important in chemical processing and laboratory applications where evaporation, heating, or process conditions may increase concentration during use.

Material selection should therefore use compatibility information that matches the expected concentration as closely as possible.

3. Evaluate Temperature

Chemical resistance and temperature should always be evaluated together.

Higher temperatures can accelerate chemical interaction with polymers and may also reduce mechanical strength or stiffness.

A material that performs adequately at room temperature may not provide the same performance when the chemical is heated.

Consider:

• Normal fluid temperature
• Maximum operating temperature
• Cleaning temperature
• Thermal cycling
• Short-duration temperature peaks

This is one reason high-performance polymers such as PPS and PEEK are frequently considered for applications combining chemical exposure with elevated temperatures. AccuMolds' PPS guidance, for example, identifies chemical resistance together with thermal stability and dimensional accuracy as key reasons PPS is used in demanding industrial and fluid-control applications.

4. Understand Exposure Time

Short-term contact and continuous immersion are very different conditions.

Chemical exposure may be:

• Occasional splash
• Intermittent contact
• Repeated cleaning
• Continuous fluid contact
• Full immersion
• Long-term vapor exposure

A plastic may tolerate brief contact but gradually change after months or years of exposure.

For long-service-life products, engineers should evaluate whether chemical interaction could affect performance over the expected operating period.

Testing from resin suppliers can provide useful screening information, but representative long-term validation may still be required for critical components.

5. Consider Mechanical Stress

Chemical resistance cannot always be evaluated independently from mechanical stress.

A molded component under tension, assembly load, residual molding stress, or repeated loading may be more vulnerable to certain chemical environments.

This is particularly important for:

• Snap fits
• Press-fit components
• Threaded parts
• Transparent housings
• Clamped components
• Pressure-containing parts

Poor molding conditions can also create residual stress that reduces chemical durability.

Material selection, part design, gate location, wall thickness, processing conditions, and assembly method should therefore be reviewed together.

Common Chemical-Resistant Injection Molding Materials

Different polymers provide different combinations of chemical resistance, temperature capability, mechanical performance, processability, and cost.

The following materials are commonly evaluated for chemically exposed injection molded components.

Polypropylene (PP)

PP is frequently considered for chemically exposed applications because it offers a useful combination of low density, low moisture absorption, processability, and resistance to many aqueous chemical environments.

Typical applications may include:

• Laboratory components
• Containers
• Fluid-handling parts
• Chemical-related housings
• Caps and closures

PP can be an effective material when the operating temperature and mechanical requirements remain within the capability of the selected grade.

Its relatively economical material and processing costs also make it attractive for high-volume production.

However, compatibility with specific solvents and operating conditions must still be verified.

High-Density Polyethylene (HDPE)

HDPE is another widely considered polyolefin for chemically exposed components.

It combines:

• Good toughness
• Low moisture absorption
• Chemical durability
• Impact resistance
• Cost-effective processing

Typical applications include containers, fluid-related components, protective products, and industrial parts.

Compared with PP, HDPE generally provides greater flexibility and strong impact toughness, while PP often provides higher stiffness and temperature capability.

The better material depends on both chemical exposure and functional requirements.

POM / Acetal

POM is often selected for mechanical components requiring chemical resistance together with dimensional stability, stiffness, and low friction.

Applications may include:

• Valves
• Gears
• Mechanical controls
• Pump components
• Precision fluid-handling parts

Commercial acetal copolymers are specifically used in applications involving fuels, solvents, and fluid-management environments.

POM is particularly useful when the component must function as a precision moving part rather than simply contain a chemical.

However, compatibility should still be verified against the specific chemical and temperature conditions.

Nylon (PA)

Nylon offers excellent mechanical strength, toughness, wear resistance, and fatigue performance, making it attractive for chemically exposed structural components.

Some Nylon grades provide strong resistance to oils, fuels, and hydrocarbons. However, the behavior varies significantly between PA6, PA66, specialty polyamides, modified grades, and reinforced materials. BASF's chemical-resistance guidance specifically notes that modified and reinforced Nylon grades may behave differently from unmodified base polymers.

Moisture absorption must also be considered because it can influence dimensions and mechanical properties.

Nylon should therefore be evaluated at the specific grade level.

PPS

PPS is a high-performance engineering plastic frequently selected when chemical resistance must be combined with:

• Elevated-temperature performance
• Dimensional stability
• Electrical properties
• Low moisture absorption
• Long-term reliability

It is used in components such as:

• Valves
• Pump parts
• Fluid-control components
• Fuel-system parts
• Sensor components
• Industrial equipment

AccuMolds' existing PPS Guide identifies resistance to fuels, solvents, acids, bases, automotive fluids, and cleaning agents as a key reason PPS is used in demanding applications.

The tradeoff is greater material cost and more demanding molding conditions compared with general-purpose polymers.

PEEK

PEEK is often evaluated for extremely demanding chemical environments where chemical resistance must coexist with high temperature, mechanical loading, wear, or long service life.

Potential applications include:

• Chemical processing components
• Semiconductor equipment
• High-performance valves
• Pump components
• Analytical equipment
• Aerospace fluid systems
• Oil and gas equipment

Victrex describes PEEK as resistant to a wide range of acids, bases, hydrocarbons, and organic solvents, and its published chemical-resistance data use controlled exposure testing rather than simple material-family assumptions.

PEEK can provide exceptional performance, but its material and processing cost means it should normally be selected when the application genuinely requires that performance level.

What About PEI, PC, and ABS?

PEI, PC, and ABS can also be appropriate in selected chemical environments, but they should not automatically be treated as universal chemical-resistant materials.

PEI may be considered when heat resistance, stiffness, electrical performance, and dimensional stability are also important.

PC is commonly selected for impact-resistant transparent components but can be sensitive to certain chemical environments and stress conditions.

ABS offers balanced performance and good manufacturability for general-purpose housings but is usually not the first material selected for aggressive chemical exposure.

When chemical resistance becomes the dominant design requirement, other material families may provide a better starting point.

Chemical Resistance vs Other Engineering Requirements

Selecting the material with the highest chemical resistance does not necessarily produce the best component.

Engineers must also evaluate:

Mechanical Performance

Does the component require stiffness, impact strength, fatigue resistance, or wear resistance?

Dimensional Stability

Will swelling, moisture, temperature, or molding shrinkage affect critical tolerances?

Temperature

Will the chemical be hot during operation?

Friction and Wear

Does the component slide, rotate, or contact another surface?

Regulatory Requirements

Does the application require medical, food-contact, electrical, or other certified grades?

Manufacturing Cost

Does the application genuinely require PPS or PEEK, or can PP, HDPE, POM, or another material meet the requirement more economically?

The best material is the one that satisfies the complete engineering specification rather than maximizing a single property.

Injection Molding Considerations

Chemical-resistant materials can also introduce different molding requirements.

Depending on the polymer, engineers may need to consider:

• Material drying
• Melt temperature
• Mold temperature
• Gate design
• Venting
• Fiber orientation
• Shrinkage
• Cooling
• Tool wear
• Residual stress

For example, reinforced PPS may require greater attention to tooling wear, while high-performance PEEK requires substantially more demanding thermal processing than PP or HDPE. AccuMolds' current PPS material guidance likewise emphasizes mold temperature, tooling materials, gate design, shrinkage, and DFM as part of successful production.

Chemical resistance therefore needs to be considered together with manufacturing feasibility.

A Practical Chemical-Resistant Material Selection Process

A useful workflow is:

1. Identify all chemicals
Include process fluids, cleaners, lubricants, and secondary exposures.

2. Define exposure conditions
Document concentration, temperature, duration, and pressure where applicable.

3. Define mechanical requirements
Include loads, impact, fatigue, friction, and dimensional tolerances.

4. Screen suitable material families
Eliminate polymers that clearly cannot meet the chemical or temperature environment.

5. Select specific resin grades
Review manufacturer chemical-resistance data, reinforcement, additives, and required certifications.

6. Perform DFM review
Evaluate geometry, wall thickness, gating, shrinkage, stress, and tooling requirements.

7. Validate under representative conditions
For critical applications, test molded components using realistic chemicals, temperature, time, and mechanical loading.

This approach reduces the risk of selecting a material based on one isolated datasheet property.

Need Engineering Support?

Selecting a chemical-resistant injection molding material requires balancing chemical compatibility with temperature, mechanical performance, dimensional requirements, manufacturability, and cost.

AccuMolds can help evaluate material options together with your chemical environment, part geometry, tolerances, wall thickness, gate strategy, tooling requirements, and expected production volume.

Our engineering support covers material selection, DFM analysis, precision mold development, injection molding, inspection, and scalable production.

For project evaluation, send us your 2D or 3D CAD files together with the chemicals involved, operating temperature, concentration where applicable, material requirements, quantities, tolerances, and application information. AccuMolds' current quotation process specifically accepts CAD files, material requirements, annual production volume, surface finish, tolerances, and project timing for DFM review and quotation.
