Robotics

Introduction

Robotic systems depend on a combination of mechanical structures, sensors, actuators, electronics, cables, and control components working together with repeatable accuracy.

Injection molded plastic parts are often used throughout these systems to protect electronics, organize wiring, support sensors, reduce component weight, provide assembly interfaces, and create complex geometries that would be less efficient to manufacture through traditional machining.

Typical robotic applications can include industrial robots, collaborative robots, automated handling systems, inspection equipment, mobile robots, end-of-arm tooling, and other automated machinery.

However, designing plastic components for robotics requires more than converting an existing metal component into plastic.

Robotic parts may be exposed to repeated motion, vibration, assembly loads, temperature changes, oils, cleaning agents, and tight positional requirements. Successful injection molding therefore depends on balancing part geometry, material behavior, tooling, tolerances, and production consistency from the beginning of the project.

Where Injection Molded Parts Are Used in Robotics

Injection molded components can support many functional areas within robotic and automation systems.

Typical applications include:

• Sensor housings
• Encoder covers
• Control-module housings
• Protective covers
• Cable guides
• Cable-routing brackets
• Connector housings
• Gripper components
• End-of-arm tooling covers
• Lightweight structural supports
• Motor and actuator covers
• Switch and interface housings
• Mobile-robot enclosures
• Mounting brackets
• Internal electronic supports

The requirements for these parts vary considerably.

A cosmetic protective cover may primarily need impact resistance and dimensional consistency, while a sensor housing may require precise alignment. A cable-routing component must control movement without interfering with robot articulation, while a mounting bracket may need stiffness with minimal mass.

This is why robotic plastic components should be reviewed according to their specific functional role rather than treated as generic molded parts.

Dimensional Stability for Robotic Assemblies

Repeatable positioning is one of the most important characteristics of many robotic systems.

The plastic component itself may not control the final positioning accuracy of the robot, but dimensional variation can still influence:

• Sensor location
• Connector alignment
• Assembly fit
• Bearing or actuator interfaces
• Cable-routing geometry
• Mounting positions
• Cover clearances

For this reason, designers should identify critical dimensions early in the development process.

Not every feature requires a tight tolerance.

Applying unnecessarily tight tolerances across an entire molded component can increase tooling complexity, inspection requirements, and production cost.

A better approach is to distinguish critical functional dimensions from secondary cosmetic or non-functional features.

Material shrinkage, wall thickness, mold design, cooling, and part geometry should then be considered around the features that directly affect robotic assembly performance.

Sensor and Electronics Housings

Modern robotic systems often use multiple sensors, encoders, controllers, and communication components.

Injection molded housings can provide:

• Component positioning
• Electrical isolation
• Environmental protection
• Cable interfaces
• Mounting features
• Internal ribs and supports
• Connector integration

For sensor housings, dimensional stability around mounting and locating features can be especially important.

Localized thick sections near bosses or internal supports can create uneven shrinkage that changes the position of critical interfaces.

Instead of simply increasing wall thickness for stiffness, designers can use ribs, gussets, and controlled wall transitions to reinforce the housing more efficiently.

Internal features should also be reviewed for mold access, draft, ejection, and tool complexity before tooling begins.

Lightweight Design for Moving Robotic Components

Weight can become particularly important when a molded component is located on a moving robot arm, gripper, wrist assembly, or end-of-arm tool.

Additional mass at the end of a robot arm can contribute to higher system loads and inertia.

Injection molding allows designers to reduce unnecessary material while maintaining structural support through features such as:

• Thin nominal walls
• Ribs
• Gussets
• Cored bosses
• Open structural sections
• Curved reinforcing geometry
• Part consolidation

The goal is not simply to make every wall thinner.

Material should remain concentrated around load paths, mounting interfaces, fastening points, and areas that control stiffness.

Low-load regions can then be opened or reduced where appropriate.

This approach creates a more efficient structure than uniformly reducing thickness across the entire part.

Ribs, Bosses, and Mounting Features

Ribs and bosses are commonly used in robotic housings and structural plastic components.

Ribs can improve stiffness while using less material than a thick solid wall.

Bosses may support:

• Fasteners
• Locating pins
• Inserts
• Mounting interfaces
• Alignment features

Poorly designed ribs and bosses, however, can create concentrated material buildup.

Potential molding problems include:

• Sink marks
• Localized shrinkage
• Warpage
• Longer cooling time
• Dimensional variation

Where practical, bosses should be cored rather than made as large solid cylinders.

Rib thickness should also remain balanced with the surrounding nominal wall.

Smooth transitions between bosses, ribs, and walls can help improve cooling consistency and reduce abrupt changes in material thickness.

Cable Management and Motion Requirements

Cable management is a particularly important consideration in robotic systems because cables may move repeatedly with robot joints and end effectors.

Injection molded guides, clips, covers, and routing components can help organize:

• Power cables
• Sensor wiring
• Pneumatic lines
• Communication cables

However, cable-management geometry must be designed around actual motion.

Engineers should consider:

• Cable bend radius
• Motion range
• Clearance
• Connector access
• Assembly sequence
• Retention features
• Potential abrasion areas

A molded cable guide that works in a static CAD assembly may interfere with movement once the robot begins cycling.

Prototype evaluation and assembly checks can therefore be valuable before production tooling is finalized.

Material Selection for Robotic Components

Material selection should be based on the operating environment and functional requirements of each robotic component.

Important factors can include:

• Stiffness
• Impact resistance
• Dimensional stability
• Wear behavior
• Temperature resistance
• Chemical resistance
• Moisture behavior
• Electrical properties
• Weight
• Surface requirements

Depending on the application, engineers may evaluate ABS, polycarbonate, nylon, POM, PPS, PEI, PEEK, or other engineering thermoplastics.

There is no single “best robotics plastic.”

For example, a protective electronics cover and a moving structural support may require very different material characteristics.

If reinforced polymers are considered, designers should also account for how material flow and reinforcement orientation may affect shrinkage and dimensional behavior.

Material selection should therefore be considered together with geometry rather than treated as a separate decision after the part is already designed.

Environmental and Chemical Exposure

Robotic systems used in industrial environments may encounter conditions that differ significantly from controlled office or laboratory environments.

Depending on the application, molded components may be exposed to:

• Lubricants
• Oils
• Cleaning chemicals
• Moisture
• Dust
• Temperature variation
• Repeated vibration

The selected material should therefore be evaluated against the actual service environment.

Environmental requirements should be identified early, especially when dimensional stability, sealing interfaces, or long-term mechanical performance are important.

A material that performs well mechanically may not necessarily offer the same performance after repeated chemical or thermal exposure.

Part Consolidation in Robotic Assemblies

Injection molding also provides opportunities to combine multiple functions into a single component.

A robotic housing or support may integrate:

• Cable guides
• Mounting bosses
• Snap-fits
• Locating features
• Protective walls
• Connector supports
• Internal ribs

Part consolidation can reduce the number of individual components and assembly operations required.

It can also reduce tolerance stack-up between multiple separately manufactured parts.

However, integration should not be taken too far.

A highly complex single molded component may require sliders, lifters, complicated parting lines, or difficult ejection.

The best design balances functional integration with practical tooling and production requirements.

DFM for Robotic Plastic Components

A design may perform well in CAD while still creating unnecessary molding risks.

Before tooling, robotic components should be reviewed for factors such as:

• Wall thickness
• Draft
• Rib geometry
• Boss design
• Undercuts
• Parting-line location
• Gate feasibility
• Ejection
• Cooling
• Critical tolerances
• Material flow
• Assembly interfaces

Early DFM review allows engineers to identify these issues while design changes are still relatively easy to make.

AccuMolds' current manufacturing workflow includes product review, mold evaluation, mold design, mold manufacturing, trial and validation, and mass production, supporting this type of early manufacturability review before scalable production.

Mold Trial and Production Validation

A completed mold is not automatically ready for stable production.

Mold trials allow engineers to evaluate the interaction between:

• Material
• Part geometry
• Tooling
• Cooling
• Processing conditions

For robotic components, validation may include:

• Dimensional inspection
• Visual inspection
• Assembly fit
• Connector fit
• Sensor or interface alignment
• Warpage review
• Critical mounting dimensions
• Process stability

If problems are identified, the team can determine whether changes are needed to the component design, tooling, material, or molding process.

This is particularly important for components that must align consistently with sensors, electronics, actuators, or other precision assemblies.

Designing Robotics Components for Scalable Production

Prototype success does not always mean that a component is ready for repeatable production.

Before volume manufacturing, engineers should consider:

• Expected production quantity
• Tool durability
• Cycle consistency
• Material handling
• Cooling strategy
• Critical dimensions
• Inspection requirements
• Assembly sequence
• Process repeatability

The design should support both part performance and predictable manufacturing.

This is especially important when the same molded component will be produced repeatedly for robotic equipment that depends on consistent assembly and fit.

How AccuMolds Supports Robotics Projects

AccuMolds supports custom plastic component projects from early engineering review through tooling and scalable injection molding production.

Relevant capabilities include:

• DFM analysis
• Product and mold design review
• Material selection guidance
• Prototype development
• Mold design and manufacturing
• Mold-flow evaluation
• Trial mold adjustment
• Dimensional inspection
• Injection molding
• Production validation
• Scalable production

AccuMolds' published manufacturing process covers design review, tooling development, mold trials, acceptance inspection, and mass production, allowing manufacturing risks to be evaluated before a component moves into repeat production.

For robotics projects, this approach can help engineers review dimensional requirements, lightweight structures, material behavior, assembly interfaces, tooling feasibility, and production consistency as part of one development process.
