Design Review Process

Introduction

A successful product does not begin with manufacturing — it begins with a well-validated design.

The design review process is a structured engineering approach used to evaluate product designs before tooling development and production. By reviewing design requirements, manufacturability, materials, tolerances, and potential risks early, engineers can identify issues before they become expensive production problems.

For injection molded parts, an effective design review helps ensure:

• Better product performance
• Lower tooling risks
• Reduced manufacturing costs
• Faster product launch cycles

This guide explains the key steps of a design review process and how engineering teams can improve product development outcomes.

What Is a Design Review Process?

A design review is a formal evaluation where engineers, manufacturers, and stakeholders analyze a product design against technical and business requirements.

The goal is not only to verify whether a design works, but also to determine:

• Can it be manufactured efficiently?
• Will it meet performance requirements?
• Are there potential quality risks?
• Can production remain stable at scale?

For injection molded products, design reviews typically involve:

• Product designers
• Tooling engineers
• Manufacturing engineers
• Quality engineers
• Suppliers

Why Design Review Matters

1. Identify Manufacturing Issues Early

Many manufacturing problems originate from design decisions made before production.

A design review can identify:

• Difficult part geometries
• Insufficient draft angles
• Uneven wall thickness
• Poor gate locations
• Ejection difficulties

Resolving these issues during design is much easier and less costly than modifying completed molds.

2. Reduce Tooling Costs and Risks

Injection molds require significant investment.

A detailed design review helps engineers evaluate:

• Mold complexity
• Number of slides or lifters required
• Parting line location
• Cooling requirements
• Tool maintenance considerations

Early optimization can reduce:

• Mold modifications
• Production delays
• Unexpected tooling expenses

3. Improve Product Reliability

A product may function correctly in prototypes but fail during mass production.

Design review helps evaluate:

• Material selection
• Mechanical strength
• Assembly requirements
• Environmental conditions
• Dimensional stability

This ensures the final product performs consistently throughout its lifecycle.

Key Steps in the Design Review Process

Step 1: Review Product Requirements

The first step is confirming the product objectives.

Engineers should review:

• Functional requirements
• Operating environment
• Load conditions
• Temperature requirements
• Regulatory requirements
• Expected product lifetime

Example questions:

• What performance must the part achieve?
• What conditions will the product experience?
• Which dimensions are critical?

Step 2: Evaluate Design for Manufacturability (DFM)

DFM review focuses on whether the design can be produced efficiently.

For injection molded parts, engineers should check:

Wall Thickness

Evaluate:

• Uniform thickness
• Sink mark risks
• Cooling consistency

Draft Angle

Verify:

• Easy mold release
• Reduced surface damage
• Lower ejection force

Ribs and Bosses

Check:

• Structural reinforcement
• Proper thickness ratio
• Avoiding sink marks

Parting Line and Ejection

Review:

• Mold opening direction
• Ejector pin locations
• Cosmetic surface requirements

Step 3: Review Material Selection

Material selection directly affects product performance and manufacturing.

Engineers should consider:

Mechanical Requirements

• Strength
• Impact resistance
• Wear resistance

Environmental Conditions

• Temperature exposure
• Chemical resistance
• Moisture conditions

Manufacturing Requirements

• Shrinkage behavior
• Flow characteristics
• Mold temperature requirements

Choosing the right material early prevents performance issues later.

Step 4: Evaluate Tolerance Requirements

Not every dimension requires extremely tight tolerance.

A design review should identify:

Critical Dimensions

Examples:

• Assembly interfaces
• Sealing surfaces
• Functional connections

Non-Critical Dimensions

Examples:

• Cosmetic features
• Non-functional surfaces

Optimizing tolerances helps balance:

• Product performance
• Manufacturing capability
• Production cost

Step 5: Conduct Mold and Process Review

Before tooling begins, engineers should evaluate:

Mold Design

Review:

• Cavity layout
• Gate location
• Cooling channels
• Ejection system

Injection Process

Consider:

• Filling behavior
• Warpage risks
• Cycle time
• Process stability

Early collaboration between product and tooling engineers helps prevent production challenges.

Common Design Review Mistakes

1. Reviewing Too Late

Problem:

Design issues are discovered after tooling starts.

Result:

• Mold changes
• Delayed production
• Increased costs

Solution:

Involve manufacturing engineers early.

2. Focusing Only on Product Function

Problem:

A design may work but be difficult to manufacture.

Solution:

Consider both:

• Product requirements
• Manufacturing requirements

3. Ignoring Production Volume

Different production volumes require different approaches.

For example:

Prototype:

• Faster validation
• Lower tooling investment

Mass production:

• Optimized tooling
• Stable processes
• Long-term reliability

4. Not Considering Assembly Requirements

Poor design decisions may create:

• Assembly difficulties
• Increased labor costs
• Quality issues

Design reviews should consider the entire product lifecycle.

Design Review Checklist for Injection Molded Parts

Before moving to tooling, confirm:

• Product requirements are clearly defined
• Material selection is appropriate
• Wall thickness is optimized
• Draft angles are sufficient
• Ribs and bosses follow design guidelines
• Tolerances match functional requirements
• Gate location has been reviewed
• Ejection strategy is considered
• Mold complexity has been evaluated

Manufacturing risks have been identified

Design Review Process and DFM Collaboration

A successful design review requires communication between different engineering teams.

Typical collaboration:

When designers and manufacturers work together early, companies can achieve:

• Faster development cycles
• Lower production risks
• More predictable manufacturing results

How AccuMolds Supports Design Review

At AccuMolds, we work with customers during the early design stage to identify potential manufacturing challenges before tooling begins.

Our engineering support includes:

• DFM analysis
• Injection mold design review
• Material recommendations
• Mold flow evaluation
• Tolerance review
• Prototype validation

By combining design expertise with injection molding experience, we help customers develop reliable and production-ready components.
